Arquivo de Produtos - Norleq https://norleq.com/en/produtos/ Soluções Técnológicas Fri, 22 Oct 2021 11:25:09 +0000 en-GB hourly 1 https://norleq.com/wp-content/uploads/2020/03/cropped-Logo-Poli-Branco-32x32.png Arquivo de Produtos - Norleq https://norleq.com/en/produtos/ 32 32 V-700 Spectrophotometers https://norleq.com/en/produtos/v-700-spectrophotometers/ https://norleq.com/en/produtos/v-700-spectrophotometers/#respond Fri, 22 Oct 2021 10:52:18 +0000 https://norleq.com/produtos/v-700-spectrophotometers/ Jasco raplaced V-600 Spectrophotometers with their brand new V-700 series. For each new Spectrophotometers, please check the improvements below: [toggle title=” V-730 replaces V-630″ ] Spectral bandwidth: 1.0 nm Photometric range: -3 to 3 Abs Photometric accuracy (Tested with NIST SRM 930): ±0.0015 Abs (0 to 0.5 Abs) ±0.0025 Abs (0.5 to 1 Abs) ±0.3 […]

O conteúdo V-700 Spectrophotometers aparece primeiro em Norleq.

]]> Jasco raplaced V-600 Spectrophotometers with their brand new V-700 series. For each new Spectrophotometers, please check the improvements below:

[toggle title=” V-730 replaces V-630″ ]

  • Spectral bandwidth: 1.0 nm
  • Photometric range: -3 to 3 Abs
  • Photometric accuracy (Tested with NIST SRM 930): ±0.0015 Abs (0 to 0.5 Abs) ±0.0025 Abs (0.5 to 1 Abs) ±0.3 %T
  • RMS noise: 0.00004 Abs
  • Baseline flatness: ±0.0005 Abs (200 ~ 1000nm)[/toggle]

[toggle title=” V-750 replaces V-650″ ]

  • Photometric range: -4 to 4 Abs
  • Photometric accuracy (Tested with NIST SRM 930): ±0.0015 Abs (0 to 0.5 Abs) ±0.0025 Abs (0.5 to 1 Abs) ±0.3 %T
  • Baseline flatness: ±0.0002 Abs (200 ~ 850nm)[/toggle]

[toggle title=”V-760 replaces V-660″ ]

  • Photometric range: -4 to 6 Abs
  • Photometric accuracy (Tested with NIST SRM 930): ±0.0015 Abs (0 to 0.5 Abs) ±0.0025 Abs (0.5 to 1 Abs) ±0.3 %T
  • RMS noise: 0.00003 Abs
  • Baseline flatness: ±0.0003 Abs (200 ~ 800nm)[/toggle]

[toggle title=”V-770 replaces V-670″ ]

  • Photometric range: UV-Vis: -4 to 4 Abs  –  NIR: -3 to 3 Abs
  • Photometric accuracy (Tested with NIST SRM 930): ±0.0015 Abs (0 to 0.5 Abs) ±0.0025 Abs (0.5 to 1 Abs) ±0.3 %T
  • Baseline flatness: ±0.0002 Abs (200 ~ 2500nm)[/toggle]



O conteúdo V-700 Spectrophotometers aparece primeiro em Norleq.

]]> https://norleq.com/en/produtos/v-700-spectrophotometers/feed/ 0 USP Dissolution 4 – flow-through cell https://norleq.com/en/produtos/usp-dissolution-4-flow-through-cell/ https://norleq.com/en/produtos/usp-dissolution-4-flow-through-cell/#respond Fri, 22 Oct 2021 10:52:18 +0000 https://norleq.com/produtos/usp-dissolution-4-flow-through-cell/ EN

O conteúdo USP Dissolution 4 – flow-through cell aparece primeiro em Norleq.

]]> EN

O conteúdo USP Dissolution 4 – flow-through cell aparece primeiro em Norleq.

]]> https://norleq.com/en/produtos/usp-dissolution-4-flow-through-cell/feed/ 0 DisiTest 50 – Automatic tablet disintegration tester https://norleq.com/en/produtos/disitest-50-automatic-tablet-disintegration-tester/ Fri, 22 Oct 2021 10:52:18 +0000 https://norleq.com/produtos/disitest-50-automatic-tablet-disintegration-tester/ The DisiTest 50 is a modular disintegration testing system to automatically measure disintegration time of tablets and capsules in full compliance with current Pharmacopeia. Innovative induction heating technology reduces heating times to only 3-5 minutes and completely eliminates unproductive cleaning times typically associated with conventional water bath based systems. Whether used as single station tester […]

O conteúdo DisiTest 50 – Automatic tablet disintegration tester aparece primeiro em Norleq.

]]> The DisiTest 50 is a modular disintegration testing system to automatically measure disintegration time of tablets and capsules in full compliance with current Pharmacopeia. Innovative induction heating technology reduces heating times to only 3-5 minutes and completely eliminates unproductive cleaning times typically associated with conventional water bath based systems. Whether used as single station tester or modular disintegration testing system with up to 4 independent stations, the DisiTest 50 guarantees maximum efficiency and consistent results.



O conteúdo DisiTest 50 – Automatic tablet disintegration tester aparece primeiro em Norleq.

]]> OCA 15 EC – optical contact angle measuring instrument https://norleq.com/en/produtos/oca-15-ec-optical-contact-angle-measuring-instrument/ https://norleq.com/en/produtos/oca-15-ec-optical-contact-angle-measuring-instrument/#respond Fri, 22 Oct 2021 10:52:18 +0000 https://norleq.com/produtos/oca-15-ec-optical-contact-angle-measuring-instrument/ Whether your application demands the evaluation of contact angle or drop shape, the video-based optical contact angle measuring system, OCA 15EC, is the instrument of choice where initial budgets are limited. The single direct dosing system, SD-DM, together with the electronic dosing unit, ES (both included within the ‘system’ configured, under the OCA 15EC part number) enable the […]

O conteúdo OCA 15 EC – optical contact angle measuring instrument aparece primeiro em Norleq.

]]> Whether your application demands the evaluation of contact angle or drop shape, the video-based optical contact angle measuring system, OCA 15EC, is the instrument of choice where initial budgets are limited. The single direct dosing system, SD-DM, together with the electronic dosing unit, ES (both included within the ‘system’ configured, under the OCA 15EC part number) enable the precise and accurate handling and dosing of liquids.The OCA 15EC can be easily broken down for transportation in the optional case, TBO.
Features of the featured instrument configuration:

  • The horizontal position of the sample table (in the plane of the optical path) is manually adjustable via our magnetic slide system. Movement in the vertical (Z-azis) direction can be achieved via precise adjustment of the hand wheel.
  • High performance 6x parfocal zoom lens, with integrated continuous fine focus, and adjustable observation and camera tilt angle.
  • Video measuring system with USB camera (max. 87 images/s sample rate).
  • Lighting of the optical path, with adjustable intensity without hysteresis.
  • Single direct dosing system, SD-DM, for use with standard and disposable syringes and needles.
  • One electronic dosing unit, ES, with software controlled adjustable dosing volume (min. 50 nl) and dosing rate (0.06 µl/s … 26.4 µl/s).

Access to many of the available OCA accessories.

Some of the most important components and accessories are listed below:

  • High-speed option for USB camera (max. 311 images/s sample rate).
  • Manual tilting base attachment, TBA 60M, for a maximum tilt angle of 70°.
  • Wide range of sample securing and positioning. Inc. units for foils or papers, FSH 30 and FSC 80/150, or the suction plate, SP 100, for holding thin flexible samples flat on the stage, with an adjustable suction area.
  • Electro wetting platform, EWP 100, for the analysis of sessile and pendant drops under a  definable electrical field
  • The available software modules for the OCA 15EC are:
    SCA 20 — contact angle
    SCA 21 — surface free energy
    SCA 22 — pendant drop
    SCA 23 — lamella contour

O conteúdo OCA 15 EC – optical contact angle measuring instrument aparece primeiro em Norleq.

]]> https://norleq.com/en/produtos/oca-15-ec-optical-contact-angle-measuring-instrument/feed/ 0 J1000 – Circular dichroism equipment https://norleq.com/en/produtos/j1000-circular-dichroism-equipment/ https://norleq.com/en/produtos/j1000-circular-dichroism-equipment/#respond Fri, 22 Oct 2021 10:52:18 +0000 https://norleq.com/produtos/j1000-circular-dichroism-equipment/ The J-1000 series comprises two equipments directed to two different segments of the market, the model J-1100 suitable for conventional applications and model J-1500 with a range of wavelengths with a bigger wl range for operation from UV to NIR. Both units allow simultaneous measurements of CD and LD in addition to various types of thermostatted accessories […]

O conteúdo J1000 – Circular dichroism equipment aparece primeiro em Norleq.

]]> The J-1000 series comprises two equipments directed to two different segments of the market, the model J-1100 suitable for conventional applications and model J-1500 with a range of wavelengths with a bigger wl range for operation from UV to NIR. Both units allow simultaneous measurements of CD and LD in addition to various types of thermostatted accessories . The model J-1500 has a purge system more efficient than previous models, allowing a  significantly more efficient and faster purge. The units include mercury lamp for validation of the system, automatic recognition system, fittings and a cutter for the light beam coming from the xenon lamp to  monochromator to prevent degradation of this when not in use.



O conteúdo J1000 – Circular dichroism equipment aparece primeiro em Norleq.

]]> https://norleq.com/en/produtos/j1000-circular-dichroism-equipment/feed/ 0 Dissolution according to USP IV https://norleq.com/en/produtos/dissolution-according-to-usp-iv/ https://norleq.com/en/produtos/dissolution-according-to-usp-iv/#respond Fri, 22 Oct 2021 10:52:18 +0000 https://norleq.com/produtos/dissolution-according-to-usp-iv/ For over 30 years, SOTAX has been developing USP Apparatus 4 Flow Through Cell Dissolution with experts in academia and industry. Today, SOTAX is a worldwide market leader with expertise in method development and feasibility studies, automated sampling, on-line real time analysis, and customized solutions for unique drug delivery systems. The CE 7smart is the fourth generation […]

O conteúdo Dissolution according to USP IV aparece primeiro em Norleq.

]]> For over 30 years, SOTAX has been developing USP Apparatus 4 Flow Through Cell Dissolution with experts in academia and industry. Today, SOTAX is a worldwide market leader with expertise in method development and feasibility studies, automated sampling, on-line real time analysis, and customized solutions for unique drug delivery systems.
The CE 7smart is the fourth generation of SOTAX flow-through cell systems and has been designed as the Apparatus 4 instrument made to overcome potential challenges linked to method development for a variety of dosage forms.

With the Flow-Through Cell, fresh media passes continuously across the dosage form. This is called an open loop system. A semi-automated system allows  samples to be taken simultaneously and collected in a fraction collector  or analyzed directly by UV. Complete fractions or aliquotes can be collected in an Off-line open system. It is also possible to collect samples and analyze them.
USP 4 Fixed and Small Volume Dissolution/Elution Testing…For small or fixed volume testing, the flow through cell can re-circulate the media across the dosage form. This is called a closed loop system. This can be an on-line closed loop with UV, micro volume autosampler, and even a manual sampling syringe.
The validation of the USP 4 Dissolution Testing system according to the regulations can be done by a SOTAX specially trained service engineer. The USP requires the flow rate and temperature to be qualified.

O conteúdo Dissolution according to USP IV aparece primeiro em Norleq.

]]> https://norleq.com/en/produtos/dissolution-according-to-usp-iv/feed/ 0 Petrodist 500 Q semi-automatic operation https://norleq.com/en/produtos/petrodist-500-q-semi-automatic-operation/ https://norleq.com/en/produtos/petrodist-500-q-semi-automatic-operation/#respond Fri, 22 Oct 2021 10:52:18 +0000 https://norleq.com/produtos/petrodist-500-q-semi-automatic-operation/ bench scale crude oil distillation system for semi-automatic operation quick distillation of small crude oil charges approx. 2 hrs. for complete distillation (depending on crude oil) fraction collector for automatic or manual operation operation stages follow ASTM D-2892: ATM, 100 torr, 10 torr, 2 torr column efficiency similar to ASTM D 2892 Following an increasing […]

O conteúdo Petrodist 500 Q semi-automatic operation aparece primeiro em Norleq.

]]>
  • bench scale crude oil distillation system for semi-automatic operation
  • quick distillation of small crude oil charges
  • approx. 2 hrs. for complete distillation (depending on crude oil)
  • fraction collector for automatic or manual operation
  • operation stages follow ASTM D-2892: ATM, 100 torr, 10 torr, 2 torr
  • column efficiency similar to ASTM D 2892

Following an increasing demand for crude oil distillations to analyze small quantities in a short period of time PILODIST has modified the existing HRS 500 system to be applied for the purpose of crude oil distillation at a very attractive price.

Although the distillation column is packed with Propak 316 and the controller allows to perform all required distillation runs (atmospheric and vacuum 1 – 3) the system is similar but not strictly designed  according to ASTM D-2892 – standard.
The system can be operated alternatively with fraction collector or with the
intermediate receiver for larger cut volumes as well as the determination of the actual distillation rate. Both collection systems are included in the scope of supply.

O conteúdo Petrodist 500 Q semi-automatic operation aparece primeiro em Norleq.

]]> https://norleq.com/en/produtos/petrodist-500-q-semi-automatic-operation/feed/ 0 Sample preparation equipments https://norleq.com/en/produtos/sample-preparation-equipments/ https://norleq.com/en/produtos/sample-preparation-equipments/#respond Fri, 22 Oct 2021 10:52:18 +0000 https://norleq.com/produtos/sample-preparation-equipments/ EN http://www.sotax.com/products/sample-preparation/   APW http://www.sotax.com/products/sample-preparation/apw/   TPW http://www.sotax.com/products/sample-preparation/tpw/   CTS http://www.sotax.com/products/sample-preparation/cts/

O conteúdo Sample preparation equipments aparece primeiro em Norleq.

]]> EN

http://www.sotax.com/products/sample-preparation/



APW

http://www.sotax.com/products/sample-preparation/apw/



TPW

http://www.sotax.com/products/sample-preparation/tpw/



CTS

http://www.sotax.com/products/sample-preparation/cts/

O conteúdo Sample preparation equipments aparece primeiro em Norleq.

]]> https://norleq.com/en/produtos/sample-preparation-equipments/feed/ 0 Dissolution testing – USP apparatus 1 2 5 and 6 https://norleq.com/en/produtos/dissolution-testing-usp-apparatus-1-2-5-and-6/ https://norleq.com/en/produtos/dissolution-testing-usp-apparatus-1-2-5-and-6/#respond Fri, 22 Oct 2021 10:52:18 +0000 https://norleq.com/produtos/dissolution-testing-usp-apparatus-1-2-5-and-6/ O conteúdo Dissolution testing – USP apparatus 1 2 5 and 6 aparece primeiro em Norleq.

]]>

O conteúdo Dissolution testing – USP apparatus 1 2 5 and 6 aparece primeiro em Norleq.

]]> https://norleq.com/en/produtos/dissolution-testing-usp-apparatus-1-2-5-and-6/feed/ 0 OCA 25 https://norleq.com/en/produtos/oca-25-2/ https://norleq.com/en/produtos/oca-25-2/#respond Fri, 22 Oct 2021 10:52:29 +0000 https://norleq.com/produtos/oca-25-2/ OCA 25 is a versatile contact angle measurement machine. It is equipped with a video system for angle measurement. It has two variants: OCA 25 L and OCA 25 LHT. The base unit has this characteristics. High perfomance lens (6x) High definition video camera captures 123 images/s via USB Up to 6 needles Sample maximum […]

O conteúdo OCA 25 aparece primeiro em Norleq.

]]> OCA 25 is a versatile contact angle measurement machine. It is equipped with a video system for angle measurement. It has two variants: OCA 25 L and OCA 25 LHT.

The base unit has this characteristics.

  • High perfomance lens (6x)
  • High definition video camera captures 123 images/s via USB
  • Up to 6 needles
  • Sample maximum dimension (L x W x H):
    • OCA 25: 220 x ∞ x 70 mm.
    • OCA 25L: 330 x ∞ x 70 mm.
    • OCA 25LHT: 330 x ∞ x 70 mm, HTFQ 1200 ou HTFC 1800.



O conteúdo OCA 25 aparece primeiro em Norleq.

]]> https://norleq.com/en/produtos/oca-25-2/feed/ 0
